系統類型 Passive 15”, three-way, bass-reflex

Maximum SPL Output 124dB (Continuous), 130dB (Peak)

頻率范圍 (-10dB) 32hz - 20khz

Frequency Response (-3 dB) 43Hz - 20Hz

靈敏度 95dB

系統額定功率 3200W Peak, 1600W Program, 800W Continuous

標稱阻抗 8 Ohm

輸入通道 NL4 Input, NL4 Loop-thru (+/-1 or +/-2 Selectable)

Operational Modes Passive/Bi-Amp

低頻驅動單元 2275F

MF Driver 2107H

HF 驅動程序 2432H

覆蓋范圍 60 x 40

分頻點 330hz & 2.4khz

Enclosure 18mm Duraflex coated plywood

Suspension/Mounting Single 36mm pole socket, 12 x M10 Suspension points

Handles 2

外觀顏色 Obsidian Duraflex? finish

網罩 Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing

尺寸（高 x 寬 x 厚） 476mm x 544mm x 984mm (18.74in x 21.4in x 38.74in)

重量 95.0 lbs (43.1kg)
